Manual Hidden Tea Cup Making Machine
HTCM12 is our semi automatic hidden tea cup making machine, the machine have two working position, two operators weigh the tea with table top electric weighing machine, manually put the paper tea cups and weighing machine weigh and fill tea automatically, operator put the round filter to the paper cups, press the button and the machine seal automatically. The machine speed approx 1200cups/hour, good performance and easy operation.
Introduction
1. Introduction
HTCM12 is our semi automatic hidden tea cup making machine, the machine have two working position, two operators weigh the tea with table top electric weighing machine, manually put the paper tea cups and weighing machine weigh and fill tea automatically, operator put the round filter to the paper cups, press the button and the machine seal automatically. The machine speed approx 1200cups/hour, good performance and easy operation.
2. Parameter List:
| Item | Remark and data |
| Capacity | 1300 cups/ h ( two working position) |
| Filling volume | 1-20 g/cup( tea dust , tea bag , original tea and different shape tea ) |
| Filter paper specification | Round diameter 77mm filter paper |
| Paper cup type | 7-16 oz paper cup, other cup mould customized.. |
| Put cup number/time | 2cups |
| Sealing form | Heating sealing |
| Air pressure | ≥0.6Mpa(it is supplied by buyer , air Consumption 0.2M3/min ) |
| Worker | 1-2 peoples |
| Overall diameter | WxLxH:460x800x1500mm |
| Weight | 60kgs (not count the weighing machine) |
